EN Standard Winch Compliance: WARN Series G2 Winch

15 November 2024 by Arbil Limited

Video Podcast

Arbil 4x4 has launched its first video podcast, diving deep into the innovative WARN Series G2 winch. In this video, Arbil 4x4’s Business Development Manager, Simon Picken explores the unique design and safety features of the WARN Series G2 winch, specifically built to comply with EN standards - a set of stringent European guidelines that ensure safety and quality for heavy-duty equipment. Watch the video here.

In this blog, we’ll highlight the episode’s main points, focusing on what makes the WARN Series G2 ideal for industrial and commercial applications, particularly in the demanding fields of vehicle recovery and heavy lifting.



Understanding EN Standards: What Makes the WARN Series G2 Stand Out

Not all winches meet the EN standard, a certification devised by engineers to maintain exceptional levels of safety and reliability. The WARN Series G2 is a commercial vehicle recovery winch, which meets these rigorous standards, making it a trusted choice for recovery vehicle manufacturers and companies focused on safety. The EN standard helps ensure that all elements of winching systems - like overload prevention, emergency stops, and secure mountings - are designed to minimise risk. This adherence to high standards of safety and functionality has made the WARN Series G2 a popular choice among Arbil 4x4’s client base.



Key Safety Features of the WARN Series G2 Winch

The EN-compliant WARN Series G2 winch includes several hardware components and EN standard winch accessories designed for reliability and user protection. Here’s a closer look at the specific features discussed in the video:

• Over-Load Interrupter (OLI): The OLI is a critical feature that prevents the winch from overheating by cutting off power when the load exceeds the winch’s rated capacity. This mechanism uses Ohm’s law to monitor electrical resistance within the motor, detecting when the load becomes too great. By shutting off the winch in these situations, the OLI protects both the operator and the equipment.



• Emergency Stop (E-Stop): In the event of an unexpected issue during operation, the E-Stop function allows the operator or a nearby assistant to immediately cut power to the winch. The E-Stop switch is located close to the winch itself, providing a fail-safe solution to stop the winch and prevent potential accidents.



• Wireless Safety Controller: The WARN Series G2 winch is compatible with a wireless remote control, making it easier to operate the winch from a safe distance. The wireless controller includes an E-Stop button for enhanced safety, in keeping with EN standards.



• Arbil 4x4 Winch Mount: The Series G2 mount is engineered for durability, featuring design updates that make it compatible with both 10-inch and 12-inch drum winches. The mount offers increased rigidity, ensuring that the winch remains securely attached to the vehicle frame, even during high-stress recoveries.



• Specialised EN Standard Winch Rope: The EN standards also apply to the winch rope, requiring a compacted winch rope construction with a high braking load for optimal safety. The rope’s diameter and placement on the drum must leave a safe margin, or “freeboard,” after three wraps to ensure secure operation.



Coming Up

This first episode of Arbil 4x4’s video podcast on the WARN Series G2 winch has set the stage for further discussions on top-tier 4x4 recovery equipment. Designed to meet high EN standards, the WARN Series G2 combines essential safety features with advanced engineering, providing customers with a reliable winching solution for the toughest jobs. Watch the full episode to explore the WARN Series G2’s features in action and get valuable insights from Arbil 4x4’s expert team.

Stay tuned for more episodes, where Arbil 4x4 will continue to share industry-leading products and insights into high-quality equipment that meets both commercial and industrial demands.
